• Dirt resistant and easy to clean
• Specially designed for hygiene requirements
• Used for cabinets that require better sealing under vibrating conditions
• 6 mm of compression
• Noise isolation
• Different drivers / cams available
• The lock has been tested according to the DIN EN 61373 Category 1-B for vibration and shock.
• The lock has been tested according to the GS-NV 6:2015/12 for hygiene requirements
• Working Temprature Range: -50 /+80 C M22 Nut : should be fixed with 60 Nm M10 Nut: should be fixed with 10 Nm
• Threadlocker is applied to the nut threads to get extra fastness against vibration and shock
• Max load capacity: 562 N

MATERIAL

HOUSING: Stainless Steel (AISI 316)
DRIVER: Stainless Steel (AISI 316)
CAM: Stainless Steel (AISI 304)
NUT: Stainless Steel (AISI 304)
ORING: Silicone
